Codman DirectLink ICP Gebrauchsanleitung Seite 10

EN – ENGLISH
Figure 1a
A
B
A. DirectLink ICP Module
B. ICP Extension Cable
Figure 3
A
C
C1
A. DirectLink Module
B. ICP Extension Cable
C. To attach the cable, hold the
connector so that the "fin"
points downward before
pushing into module.
C1. Fin
Figure 1b
Label on back panel of module
B
E
D
D. Cable correctly attached to the
module
E. To detach the cable, squeeze
the strain relief and then
retract it. Next, pull the cable
away from the module.
Figure 2
A
C
C1
A. DirectLink Module
B.
Patient Monitor Interface Cable
C. To attach the cable, hold the
connector so that the "fin"
points downward before pushing
into module.
C1. Fin
D. Cable correctly attached to the
module
10 10
B
E
D
E. To detach the cable, squeeze the
strain relief and then retract it.
Next, pull the cable away from
the module.
