4. EC20

4.1 Bestelldaten

Bestellnummer
Kurzbeschreibung
7EC020.60-2
Embedded Controller, x86 100 MHz Intel kompatibel, 32 MByte
DRAM, 32 KByte SRAM, tauschbarer Programmspeicher (Com-
pactFlash), 1 CAN Schnittstelle, 1 X2X Link Master Schnittstelle,
1 Ethernet Schnittstelle 100 Base-T, 1 RS232 Schnittstelle, 3 DM,
24 VDC, 0,5 A.
Programmspeicher gesondert bestellen!
Feldklemmen 0TB708 und 0TB704 gesondert bestellen!
7EC020.61-2
Embedded Controller, ARNC0, x86 100 MHz Intel kompatibel,
32 MByte DRAM, 32 KByte SRAM, tauschbarer Programmspeicher
(CompactFlash), 1 CAN Schnittstelle, 1 X2X Link Master Schnitt-
stelle, 1 Ethernet Schnittstelle 100 Base-T, 1 RS232 Schnittstelle,
3 DM, 24 VDC, 0,5 A.
Programmspeicher gesondert bestellen!
Feldklemmen 0TB708 und 0TB704 gesondert bestellen!
Programmspeicher
5CFCRD.0032-02
CompactFlash 32 MByte ATA/IDE SanDisk
5CFCRD.0064-03
CompactFlash 64 MByte ATA/IDE SiliconSystems
5CFCRD.0128-03
CompactFlash 128 MByte ATA/IDE SiliconSystems
5CFCRD.0256-03
CompactFlash 256 MByte ATA/IDE SiliconSystems
5CFCRD.0512-03
CompactFlash 512 MByte ATA/IDE SiliconSystems
5CFCRD.1024-03
CompactFlash 1024 MByte ATA/IDE SiliconSystems
5CFCRD.2048-03
CompactFlash 2048 MByte ATA/IDE SiliconSystems
5CFCRD.4096-03
CompactFlash 4096 MByte ATA/IDE SiliconSystems
5CFCRD.8192-03
CompactFlash 8192 MByte ATA/IDE SiliconSystems
Erforderliches Zubehör
0TB708.91
Zubehör Feldklemme, 8-polig, Federzugklemme, 1,5 mm²
0TB708:91-02
Zubehör Feldklemme, 20 Stk. 8-polig, Federzugklemme 1,5 mm²
0TB704.9
Zubehör Feldklemme, 4-polig, Schraubklemme, 1,5 mm²
0TB704.91
Zubehör Feldklemme, 4-polig, Federzugklemme, 2,5 mm²
Optionales Zubehör
0G0001.00-090
Kabel PC <-> SPS/PW, RS232, Online-Kabel
7AC911.9
Busstecker, CAN
0AC912.9
Busadapter, CAN, 1 CAN Schnittstelle
0AC913.92
Busadapter, CAN, 2 CAN Schnittstellen, inklusive 30 cm Anschluss-
kabel (DSUB)
Anmerkungen
Programmspeicher und Feldklemmen TB704 und TB708 gesondert bestellen!
Compact I/O System Anwenderhandbuch V 1.22

Tabelle 5: 7EC021.60-1 - Bestelldaten

Embedded Controller • EC20
Abbildung
25
