10. Troubleshooting

10. Troubleshooting
Possible Cause
malfunctions
DIP switch ON/ OFF in OFF position
There is no connection to the power supply.
TLMR does not Batteries are empty (TLMR 101)
work
Fault - storage test
Fault - overcurrent (2 hours pause)
Fault - TLMR blocked
Air in the supply line
TLMR works, but
does not dispense Cartridge is empty
lubricant
Elimination, detection of the malfunction
Put the DIP switch in the ON position. The test of the storage pro-
gram starts (10 s)
Connect the TLMR to the correct power supply
Replace the batteries
Switch the TLMR on again. The test of the storage program must
lapse automatically, i. e. the LEDs flash during 10 s following the
sample "Switch-on process".
The red LED flashes following the sample "Pause after overcurrent"
The red LED flashes following the sampe "Pause after blockade"
Remove the supply line, put the DIP switch into the "Venting" positi-
on. Let the TLMR run until lubricant is supplied free of bubbles
Green LEDs flash following the sample "Pre-empty warning"
Replace cartridge and batteries, if need be
