3.1 Lubricator

The TLMR is a compact, powerful, electri-
cally driven lubricator to supply lubricant
intermittently from special, non-refillable
SKF lubricant cartridges.
To do so the supply piston carries out a
complete supply cycle (full downward and
upward movement).
There is available a 12/24 VDC as well as a
battery version independent of the power
grid. We recommend to use the 12/24 VDC
version in areas where mainly low tempe-
ratures are to be expected.
The lubricant volume required at the lube
point can easily be adapted to the require-
ments by selecting the suitable cartridge
size and adjusting the dispensing time
(consumption time of the cartridge).
The dispensing time of the cartridges can
be set from 1 to 24 months.
18

3.2 Operation with PLC control unit

For special applications the TLMR can be
driven also with an external control unit
(PLC).
The following rules apply for an operation of
the TLMR with a PLC control unit:
○ The TLMR must be switched "ON" via the
DIP switch.
○ The power supply is switched on and off
via the PLC control unit.
○ All DIP switch settings can be used
except from "Venting" and "Reset".
○ The TLMR can be switched on maximum
twice per minute.
○ During standard operation there must
not be switched more than 2 supply cy-
cles per hour by the PLC control unit.
○ To vent the lubricator, e.g. after a change
of cartridge, a higher number of supply
cycles is possible (e.g. 10 supply cycles).
