4. Technical data

4. Technical data

4.1 General technical data

Admissible operating temperature
Operating pressure
Lubricant outlet
Installation position
Protection class
Output per supply cycle
Total output
Pumpable lubrication greases
Weight of drive unit (incl. batteries)
Electric connection
TLMR 201
Power supply
Max. power input
Protection class
TLMR 101 (battery version)
Supply voltage
Corresponding batteries are supplied with each cartridge.
Batteries have to be exchanged each time the
cartridge is changed. Afterwards carry out a reset.
* also rotating installation as usual, e.g. in wind power plants.
Maximum speed = 25 rpm.
Technical data
min. -25 °C max. 70 °C
max. 30 bar
G1/4
any*
IP 6K9K
approx. 0.12 ml
≥ 12 lubricant cartridges (380 ml)
NLGI 1 and 2
0.8 kg
12/24 VDC
< 1A
SELV (1)
4 x 1.5 V (AA)
TLMR without
cartridge
Dispensing time 6 months
Size of cartridge 380 ml
Reset OFF
Activated OFF
Cartridge
120 ml
Dispensing time
01 month 4.00 ml/d
02 months 2.00 ml/d
03 months 1.30 ml/d
06 months 0.60 ml/d
09 months 0.40 ml/d
12 months 0.30 ml/d
18 months 0.20 ml/d
24 months 0.15 ml/d
EN
4
Factory settings
with 120 ml
cartridge
3 months
120 ml
OFF
OFF
Nominal output
Cartridge
380 ml
------------
6,30 ml/d
4.20 ml/d
2.10 ml/d
1.40 ml/d
1.00 ml/d
0.70 ml/d
0.50 ml/d
