IBS PCI DDK UM
2-52
MPM Descriptor Node 1 (378A
startAddrDTA
startAddrExDTA
startAddrMXA
data[0][0] startAddrDTA
data[0][1] startAddrDTA
data[0][2] startAddrDTA
data[0][3] startAddrDTA
data[1][0] startAddrDTA
data[1][1] startAddrDTA
data[1][2] startAddrDTA
data[1][3] startAddrDTA
/* Node
svr[0][0-3] ->
svr[1][0-3] ->
avr[0][0-3] ->
avr[1][0-3] ->
snr[0][0-3] ->
snr[1][0-3] ->
):
hex
1000 -> length 1024
8C00 -> length 5120
7000 -> length 7168
1000 -> length 0000
FFFF -> length 1024
0400 -> length 1024
1C00 -> length 1024
0000 -> length 0000
FFFF -> length 1024
1400 -> length 1024
0C00 -> length 1024
0 1 2 3
3772 0000 37760000
/* SVR senden Node 0-3 */
342A 0000 3A94 0000
/* SVR empfangen Node 0-3 */
377A 0000 377E 0000
/* AVR senden Node 0-3 */
3432 0000 3A9C 0000
/* AVR empfangen Node 0-3 */
3782 00003786 0000
/* SNR senden Node 0-3 */
343A 0000 3AA4 0000
/* SNR empfangen Node 0-3 */
*/
6189A
