Choosing between several options
LANGUAGE
►
DEUTSCH
LANGUAGE
►
ENGLISH
Saving changes
SAVE USER CONF.
►
IMPORTANT (NOTE)
Unless you remember to save them, any changes will be lost (the same applies if the device
should automatically revert to the STANDARD mode because no entries have been made for
a period of 2 minutes).
During the save process, "PLEASE WAIT" will appear on the display, followed by "OK".
Hardware reset
HARDWARE RESET
►
Return to default display
END PARAMETER
►
IMPORTANT (NOTE)
For detailed information on the menu structure, a description of the parameters and a list of
possible diagnostic messages, please consult the operating instructions.
CI/FMT500-IG-X1
?
Sensyflow FMT500-IG
PROFIBUS DPV1 parameterization
When presented with several options, you can scroll
through them by pressing
The option shown will be applied as soon as you exit
the menu.
Use or to exit the menu.
To save any entries and changes you make,
remember to confirm SAVE USER CONF. by
pressing before you exit the submenu.
After changing the communication parameters
(PROFIBUS address, baud rate), you need to
perform a hardware reset by pressing
logs the device on to the master using the new data.
Use to exit the menu.
If no entries are made for a period of two minutes,
the device will revert to display mode and adopt the
STANDARD operation mode.
Any unsaved changes will be lost.
repeatedly.
. This
