4.1.4. Torque Specifications for Installation

Parameter
1 Front screws
2 Locking screw
3 Terminal blocks (small)
4 Terminal blocks (large)
5 PE
6 PG9
7 PG21
Table 4.6: Nm Specifications
Illustration 4.4: Overview of Inverter with Torque Indications

4.1.5. Mains Circuit Specifications

Maximum Inverter Current
Recommended Fuse type gL/gG 16 A
Table 4.7: Mains Circuit Specifications
No consumer load should be applied between the mains circuit breaker and the
inverter.
Note:
In case the breakers are placed closely side by side or exposed to heat, please refer to breaker
manufacturer derating guidelines.
Screwdriver
TX 30
TX 30
Straight slot 0.5x3.0 mm
Straight slot 1.0x5.5 mm
Straight slot 1.0x5.5 mm
SW 19 mm
SW 33 mm
TLX 10 k TLX 12.5 k
15 A 19 A
20 A
L00410309-03_2q
4. Technical Data
Torque
6-8 Nm
5 Nm
0.5 Nm
Min. 1.2 Nm
2.2 Nm
2-3 Nm
4-5 Nm
TLX 15 k
22 A
25 A
