4.1.1. Norms and Standards

Normative Referen-
ces
Directive LVD
Directive EMC
Safety
Integrated DC-switch
EMC immunity
EMC emission
Utility interference
CE
Utility characteristics
S0 Energy Meter
Functional Safety
Germany
Italy
Spain
Table 4.2: Norm and standards
* Deviant from paragraph 4.2.7 the isolation resistance measurement limit is set to 200 kΩ, in
accordance with authorities.

4.1.2. Where to Install and Conditions for Installation

Parameter
Evironmental class
IP
Environmental class description
It is not allowed to install the inverter on flammable construction materials or in areas where highly inflam-
mable materials are stored or in potentially explosive environments. Do not install on gypsum plaster board.
Table 4.3: Conditions for installation
Parameter
Wall Plate
Table 4.4: Wall Plate specifications
TLX 10 k TLX 12.5 k
2006 / 95/ EC
2004 / 108 / EC
VDE 0100-712
EN 61000-6-1
EN 61000-6-2
EN 61000-6-3
EN 61000-6-4
EN 61000-3-2 / -3 EN 61000-3-11 / -12
EN62053-31 Annex D
For transformerless inverter
DIN VDE 0126-1-1*
DK5940-2.2 (2007)
RD1663 (2000)
Condition
No direct sunlight
Temperature range: -25° to +60°C
Vibration: 1G
Condition
Hole diameter
Alignment
L00410309-03_2q
4. Technical Data
TLX 15 k
EN 50178
EN 61000-3-11 / -12
Yes
IEC 61727
EN 50160
RD661
Specification
In accordance with 60721-3-3
54
4K6/4B3/3C2/3S3/2M2
Specification
30 x 9 mm
Perpendicular ± 5° all angles
4
21
