3. Start-up and Check of Settings

3.1. Start-up and Check of Settings
The inverter is shipped with set limits for different countries. All country specific limits are stored
in the inverter and must be selected at installation. It is always possible to see the applied country
limits in the display. The inverter accounts for daylight saving automatically.
After installation, check all cables and then close the inverter.
Turn on AC at the mains switch.
When prompted by the display select language. This selection has no influence on the operating
parameters of the inverter and is not a country selection.
Illustration 3.1: Select language
Note:
To use the default language (English) simply press the 'OK' button twice to select and accept.
Illustration 3.2: Set time
Note:
It is very important to set the time and date accurately as the inverter uses this for logging. If
a wrong time/date is accidentally set, please correct it immediately in the set date and time
menu [Setup → Inverter details → Set date and time].
The language is set to English at initial start-
up. To change this setting press the OK but-
ton. Press '
guages. Select language by pressing 'OK'.
Set time as prompted by the display. Press
'OK' to select number. Press '
through the numbers. Select by pressing 'OK'.
L00410309-03_2q
3. Start-up and Check of Settings
' to scroll down through the lan-
▼
' to scroll up
▲
