2. Installation

2.4. Opening and Closing the Inverter

2
Illustration 2.7: Loosen front screws
Illustration 2.8: Open the inverter
10
Remember to observe all ESD safety regulations. Any electrostatic charge must be
discharged by touching the grounded housing before handling any electronic com-
ponent.
Use a TX 30 screwdriver to loosen the two
front screws. Turn the screwdriver until you
feel the screws pop up. They are secured with
a spring and cannot fall out.
Push the front cover upwards. When you feel
a slight resistance, give the front cover a tap
on the bottom to snap it into holding position.
