Illustration 2.9: Close the inverter
Illustration 2.10: Fasten front screws and ensure
proper PE connection.
The two front screws are the PE connection to the front cover. Make sure that both
screws are mounted and fastened with the specified torque.
To close the inverter, hold on to the lower end
of the front cover with one hand and give it a
tap on the top until you feel it falling into your
hand. Guide the front cover into place and
fasten the two front screws.
