2. Installation
2.7. Auxiliary Input/Output
2
Note:
For details please see the section on
The inverter has the following auxiliary input/output:
•
•
•
•
Please see the specifications for an overview of the communication board. Please refer to the
inverter user manual for details regarding auxiliary input configuration via the display.
2.8. Autotest Procedure - Italy Only
An automatic test of the inverter can be initialised by activating the Inverter Autotest Software in
the display. On the display find [Setup → Setup details → Autotest] and press OK. The autotest of
the inverter will now start automatically.
16
2 x RJ45 for RS485
1 x 8 pole terminal block for RS485
1 x 10 pole terminal block for
-
PT1000 temperature sensor input x 3
-
Irradiation sensor input
-
Energy meter (S0) input
1 x 4 pole terminal block for relay outputs
Specifications .
L00410309-03_2q
