Rise Time
Rise Time: Time that the leading edge of the first pulse in the waveform
takes to rise from 10% to 90% of its amplitude.
Fall Time: Time that the falling edge of the first pulse in the waveform
+Width: The width of the first positive pulse in 50% amplitude points.
-Width:
Delay
Delay
+Duty: +Duty Cycle, defined as +Width/Period.
-Duty:

How to Measure with Cursors

Press the Cursor button to display the cursor measurement function menu
in the bottom menu. If there is already a cursor measure window at the top
right, you can touch it to display the Cursor Measure Menu too.
The Cursor Measurement for normal mode:
The cursor measurement includes Voltage Measurement and Time
Measurement at normal mode.
The description of the cursor measurement menu is shown as the
following table:
Fall Time
+Width
Figure 0-9
takes to fall from 90% to 10% of its amplitude.
The width of the first negative pulse in the 50% amplitude
points.
and Delay
and Delay
-Duty Cycle, defined as -Width/Period.
-Width
: The delay between the two channels at
the rising edge.
: The delay between the two channels at
the falling edge.
141
