How to Implement the General Inspection

After you get a new oscilloscope, it is recommended that you should make a
check on the instrument according to the following steps:
1. Check whether there is any damage caused by transportation.
If it is found that the packaging carton or the foamed plastic protection cushion
has suffered serious damage, do not throw it away first till the complete device
and its accessories succeed in the electrical and mechanical property tests.
2. Check the Accessories
The supplied accessories have been already described in the "Anhang A: " of
this Manual. You can check whether there is any loss of accessories with
reference to this description. If it is found that there is any accessory lost or
damaged, please get in touch with the distributor of your device responsible for
this service.
3. Check the Complete Instrument
If it is found that there is damage to the appearance of the instrument, or the
instrument cannot work normally, or fails in the performance test, please get in
touch with your distributor responsible for this business. If there is damage to
the instrument caused by the transportation, please keep the package. With
the transportation department or your distributor responsible for this business
informed about it, a repairing or replacement of the instrument will be arranged
by PeakTech.

How to Implement the Function Inspection

Make a fast function check to verify the normal operation of the instrument,
according to the following steps:
1. Connect the power cord to a power source. Push down the button of the
" " signal on the left bottom.
The instrument carries out all self-check items and shows the Boot Logo.
Press the "Utility" button, select Calibrate in the left menu, select Factory Set
in the bottom menu. The default attenuation coefficient set value of the probe
in the menu is 10X.
2. Set the Switch in the Oscilloscope Probe as 10X and Connect the
Oscilloscope with CH1 Channel.
Align the slot in the probe with the plug in the CH1 connector BNC, and then
tighten the probe with rotating it to the right side.
Connect the probe tip and the ground clamp to the connector of the probe
compensator.
