Figure 0-3 Set the network parameters of the Software
(4) Set the network parameters of the oscilloscope. In the oscilloscope, Press
the Utility button, select Config in the left menu. Select Net Config in the
bottom menu. Set the IP Address and Port to the same value as the
"Ports-settings" in the software in step (3). You can refer to "
(5) " on P50. ouch
T
the software, the connection is successful.
Figure 0-4 Set the network parameters of the oscilloscope

Connect through a router

(1) Connection. Use a LAN line to connect the oscilloscope with a router, the LAN
port of the oscilloscope is in the rear panel; the computer should be connected
to the router too.
(2) Set the network parameters of the computer. Since the oscilloscope cannot
support obtaining an IP address automatically, you should assign a static IP
address. The Default gateway and Subnet mask should be set according to
the router. Here we set the IP address to 192.168.1.71, Subnet mask is
255.255.255.0, Default gateway is 192.168.1.1.
to complete the setting. If you can get data normally in
150
