Safety Symbols

Symbols on the product. The following symbol may appear on the product:
Hazardous Voltage
Protective Earth Terminal
Test Ground
To avoid body damage and prevent product and connected equipment damage,
carefully read the following safety information before using the test tool. This
product can only be used in the specified applications.
Warning
:
The 4 channels of the oscilloscope are non-isolated electrically. The
channels should adopt common basis during measuring. To prevent short
circuits, the 2 probe ground must not be connected to different non-isolated
DC level.
Warning
:
The channels should adopt common basis during measuring. To prevent
short circuits, the 2 probe ground must not be connected to 2 different
non-isolated DC level.
The diagram of the oscilloscope ground wire connection:
Signal Input
Ground Clip
It is not allowed to measure AC power when the AC-powered oscilloscope is
connected to the AC-powered PC through the ports.
Oscilloscope
Probe
90
Refer to Manual
Chassis Ground
Electrical Outlet
Power Cord
