7.Demonstration

Example 1: Measurement a Simple Signal

The purpose of this example is to display an unknown signal in the circuit, and
measure the frequency and peak-to-peak voltage of the signal.
1. Carry out the following operation steps for the rapid display of this
signal:
(1) Set the probe menu attenuation coefficient as 10X and that of the switch in
the probe switch as 10X (see "
(2) How to Set the Probe Attenuation
(3) Connect the probe of Channel 1 to the measured point of the circuit.
(4) Press the Autoset button.
The oscilloscope will implement the Autoset to make the waveform optimized,
based on which, you can further regulate the vertical and horizontal divisions
till the waveform meets your requirement.
2. Perform Automatic Measurement
The oscilloscope can measure most of the displayed signals automatically. To
measure the period and frequency of the Channel 1 and the mean and
peak-to-peak voltage of the Channel 2, follow below steps:
(1) Press the Measure button.
(2) Select Add in the bottom menu.
(3) Select Source in the right menu; select ① in the left menu.
(4) Select Type in the right menu; select Period in the left menu.
(5) Select Add in the right menu, the period options added completes.
(6) Select Freq in the left menu.
(7) Select Add in the right menu, the frequency added completes, finish
setting of CH1.
(8) Select Source in the right menu; select ② in the left menu.
(9) Select Type in the right menu; select Mean in the left menu.
(10) Select Add in the right menu, the Mean added completes.
(11) Select PK-PK in the left menu.
(12) Select Add in the right menu, the PK-PK added completes, finish setting of
CH2.
The measured value will be displayed at the bottom left of the screen automatically
Coefficient
" on P101).
153
