Specifications - Stihl Rt 4082.1 Gebrauchsanleitung

18 Specifications

Beeps
Error Cause
A steady beep There is an error in the electro‐
sounds. nics or in the battery.
The grass catcher box is full.
18 Specifications
18.1 STIHL RT 4082.1 Ride-on
Mower
Engine
– Engine type: EVC 4000
– Displacement: 452 cm³
– Engine power (P): 8.2 kW (11.1 PS) at
2700/min
– Engine speed (n): 2700rpm
– Max. fuel tank capacity: 6 l
Battery and electrical system
– Battery type: Lead gel
– Rated voltage: 12 V
– Charging device fuse: 15 A
– Electrical fuse system: 10 A
– Main fuse: 150 A
– Minimum voltage of battery: 11.5 V
Machine
– Maximum forward driving speed:
– 9.9 km/h
– Maximum reverse driving speed:
– 4.6 km/h
– Weight (m) with empty grass catcher box and
including mowing deck:
– 204 kg
– Maximum grass catcher box capacity: 250 l
– Cutting width: 80 cm
– Tire dimensions, front: 15x6.00-6
– Tire pressure, front: 0.9–1.2 bar
– Tire dimensions, rear: 16x6.50-8
– Tire pressure, rear: 0.7–1.0 bar
– Maximum tongue weight: 40 kg
– Maximum pulled load: 40 kg
0478-193-9806-A
Remedy
► Turn the ignition key to the "Engine off" position.
► Check if the battery is correctly installed.
► If the clamps are attached to the wrong terminals:
Insert the battery as described in this User
Manual.
► If the battery is correctly installed and the error
persists: There is an error in the electronics. Do
not use the ride-on mower and instead contact a
STIHL authorized dealer.
Empty the grass catcher box.
Machine dimensions
a = 87 cm, b = 90 cm, c = 114 cm, d = 177 cm,
e = 213 cm, f = 110 cm, g = 117 cm
18.2 Blades
– Minimum thickness a: 2.5 mm
– Minimum width b: 65 mm
– Sharpening angle c: 30°
18.3 Sound and vibration values
STIHL recommends wearing hearing protection.
RT 4082.1
The K-value for the sound pressure level is
2 dB(A). The K-value for the sound power level is
0.7 dB(A). The K-value for the vibration level at
the seat is 0.60 m/s². The K-value for the vibra‐
tion level at the steering wheel is 3.00 m/s².
– Sound pressure level L
ance with EN ISO 5395-3: 86 dB(A)
– Guaranteed sound power level L
ured in accordance with 2000/14/EC:
100 dB(A)
– Vibration value a
accordance with EN ISO 5395-3: 0.60 m/s²
– Vibration value a
ured in accordance with EN ISO 5395-3:
3.00 m/s²
measured in accord‐
pA
meas‐
WAd
at seat, measured in
w
at steering wheel, meas‐
hw
English
83
