In Video Trigger mode, the trigger setting information is displayed on
bottom right of the screen, for example,
that trigger type is Video, trigger source is CH1, and Sync type is
Even.
Video Trigger menu list:
MENU SETTIN
Type Single
Single
Source
NTSC
Modu
SECAM
Next
Page
Sync
Line NO.
Prev
Page
INSTRUCTION
G
Set vertical channel trigger type as single
trigger.
Set vertical channel single trigger type as
Video
video trigger.
CH1 Select CH1 as the trigger source
CH2 Select CH2 as the trigger source
PAL
Select video modulation
Enter next page
Line Synchronic trigger in video line
Field Synchronic trigger in video field
Odd Synchronic trigger in video odd filed
Even Synchronic trigger in video even field
Synchronic trigger in designed video line.
Press Line NO. menu item, turn the M knob
to set the line number.
Enter previous page
