Figure 3- 8 Attenuation Switch
Caution:
When the attenuation switch is set to 1X, the probe will limit
the bandwidth of the oscilloscope in 5MHz. To use the full
bandwidth of the oscilloscope, the switch must be set to 10X.

How to Use the Probe Safely

The safety guard ring around the probe body protects your finger
against any electric shock, shown as Figure 3- 9.
Figure 3- 9 Finger Guard
21
