5. Installation

5.1 Check for Physical Damage

Make sure the inverter is intact during transportation. If there is any visible
damage, such as cracks, please contact your dealer immediately.

5.2 Packing List

Open the package and take out the product, please check the accessories first.
The packing list shown as below.
A
F
K
Object Quantity
A 1
B 1
C 6
D 6
E 1
F 12
G 1
H 1
atx054en0225
B
G
L
Beschreibung
Inverter
Bracket
PV connectors
(3*positive, 3*negative)
PV pin contacts
(3*positive, 3*negative)
AC connectors
6*Expansion tubes &
6*Expansion screws
Earth terminal
Communication connector
C
Quick
Installation Guide
& Bedienungs-
anleitung
H
M
Object Quantity
I 1
J 1
K 3
L 2
M 2
N 4
O 1
D
I J
N O
Beschreibung
Quick installation guide and
User manual
3ph Meter <80A
Hexagonal screws
Battery connectors
(1*positive, 1*negative)
Battery pin contacts
(1*positive, 1*negative)
Ethernet cable terminal
Antenna
