Installation guide / User manual
AX Plus 5-15kW 3ph Hybrid Inverter
6.12 EPS Connection (Non-parallel State)
Common loads description
Under EPS mode, if need to connect the inductive load on EPS port, please ensure
that the instantaneous power of the load at startup is lower than the maximum
power of the EPS mode. Below table shows some conventional and reasonable
loads for you reference. Please refer to your loads' manual for the actual specs.
Power
Type
Start
Resistive
X1
load
Capacitive
X2
load
Inductive
X3~5
load
• Unipolar load is not supported.
• Half-wave load is not supported.
• For some motor loads, the starting current may be far more than 5 times the
current, which is also not supported.
atx054en0225
Common
equipment
Rated
X1
Incandescent
lamp
X1,5
Fluorescent lamp
X2
Fan
Equipment
100W
Incandescent
TV
lamp
40W
Fluorescent
lamp
150W
Fridge
Fridge
Example
Start
Rated
100VA (W)
100VA (W)
80VA (W)
60VA (W)
450~750
300VA (W)
VA (W)
Page 121
