Installation guide / User manual
AX Plus 5-15kW 3ph Hybrid Inverter
Insert L1/L2/L3/N wires, CT and RS485A/B cable into the meter.
Please refer to the meter wiring diagram on side of meter itself.
To Inverter-L
To Grid-L
NOTE:
The 2,5,8 of the CT meter are connected to the three live wires L1, L2, and
L3 respectively.
The transformation ratio setting of a CT meter needs to be consistent with the
transformation ratio of a CT meter. The transformation ratio setting method.
For a CT meter is as follows:
Power on
Measure
display
Character
interface
Ct
_
atx054en0225
CT
CT
CT
Press for once
SET
codE
twice
SET
701
once
SET
_0
once
SET
60_
once
_01
Add
four
40
24:RS485A
25:RS485B
once
601
Add
once
SET
Shift
twice
ESC
Measure
display
Page 117
