Installation guide / User manual
AX Plus 5-15kW 3ph Hybrid Inverter
• In installations where the local electric code requires an RCD with a lower
leakage setting, the discharge current might result in nuisance tripping of the
external RCD. The following steps are recommended to avoid nuisance tripping
of the external RCD:
• Selecting the appropriate RCD is important for correct operation of the
installation. An RCD with a rating of 30mA may trip at a leakage as 15mA
(according to IEC 61008). High quality RCDs will typically trip at a value closer to
their rating.
3. Introduction
3.1 Basic Features
AX Plus series are high-quality inverters which can convert solar energy to AC
energy and store energy into battery. The inverter can be used to optimize self-
consumption, store in the battery for future use or feed-in to public grid. Work
mode depends on PV energy and user's preference.
System advantages:
• Advanced DSP control technology.
• Utilizes the latest high-efficiency power component.
• Advanced anti-islanding solutions.
• IP65 protection level.
• Max. Efficiency up to 98%. EU efficiency up to 97.3%. THD<3%.
• Safety & Reliability: Transformerless design with software and hardware protection.
• Export limitation (Meter/DRM0/ESTOP).
• Power factor regulation. Friendly HMI.
• LED status indications.
• LCD display technical data, human-machine interaction through four touch keys.
• PC remote control.
•System connection diagrams
NOTE:
According to Australian safety requirements, the neutral cables of the on-
grid side and backup side must be connected together. Otherwise, the
backup function will not work.
Page 80
atx054en0225
