Installation guide / User manual
AX Plus 5-15kW 3ph Hybrid Inverter
Export control setting:
SETTINGS
The electricity meter is connected as follows:
Legend
Active L1/L2/L3
Neutral N
Earth PE
RS485 A
RS485 B
L1
L2
L3
N
PE
Meter connection:
Meter Connection Diagram
atx054en0225
ON-GRID PARM
24 25
To Inverter-L
To Grid-L
EXPORT CONTROL
Logger Logger
485B 485A
To Inverter-N
24:RS485A
25:RS485B
To Grid-N
xxxxx W
L1
L2
L3
N
PE
Page 115
L1
L2
L3
N
PE
