Installation guide / User manual
AX Plus 5-15kW 3ph Hybrid Inverter
6.8 RJ45 connection
The machine has three RJ45 terminals,
which are meter, Ethernet, and RCR functions.
The definition of meter port pin is as follows:
PIN
1
Port
Meter
Meter
485B
The definition of Ethernet port pin is as follows:
PIN
1
Port
Ethernet
TX+
The definition of DRM port pin is as follows:
PIN
1
Port
DRM
+3.3V
RJ45-Wiring
Installation Procedure
Insert the network cable into the wire-locking nut, sealing plug and mainbody
in turn. The sealing plug is stuck into the network cable through the gap on the
sealing side.
Insert the network cable plug into
the matched RJ45 panel mount connector.
Tighten the connector mainbody by the open-ended
wrench into the RJ45 panel mount connector
with a torque 1.2±0.2N·m
atx054en0225
2
3
Meter
/
485A
2
3
TX-
RX+
2
3
DRM1
DRM2
4
5
/
/
4
5
/
/
4
5
DRM3
DRM4
Stuck into the network cable
through the gap on the sealing side.
6
7
Meter
/
485B
6
7
/
RX-
6
7
DRM0
GND
8
Meter
485A
8
/
8
GND
Page 107
