Installation guide / User manual
AX Plus 5-15kW 3ph Hybrid Inverter
4. Technical Data
Specification
Order number
PV Input
Max. Array Power [Wp]
Max. DC Input Power [W]
Max. DC Voltage [V]
Norminal DC Operating Voltage [V]
Max. MPPT Input Current [A]
Max. MPPT Short Circuit Current [A]
Max. MPPT Input Power [W]
Min. Operating PV Voltage [V]
MPPT Voltage Range [V]
Start-up Input Voltage [V]
No. of MPP Trackers
Strings per MPP Tracker
Battery
Battery Type
Battery Voltage [V]
Min. Operating Battery Voltage [V]
Min Battery Voltage @Full AC Load [V]
Max. Charge / Discharge Current [A]
Communication Interface
AC Output
Norminal AC Power [W]
Max. Apparent AC Power [VA]
Rated Grid Voltage (AC Voltage Range) [V]
Rated Grid Frequency [Hz
Rated AC Current [A] (Per Phase)
Max. AC Current [A] (Per Phase)
Power Factor
THDI [%]
AC input
Max. AC Power [VA]
Rated Grid Voltage (AC Voltage Range) [V]
Rated Grid Frequency [Hz]
Max. AC Current [A] (Per Phase)
EPS Output
Max. Apparent AC Power [VA]
Peak Apparent AC Power [VA] (60s)
Rated Output Voltage [V]
Rated Grid Frequency [Hz]
EPS Max. Current [A] (Per Phase)
Power Factor
Switch Time [ms]
THDV [%]
atx054en0225
AX Plus 5kW
AX Plus 6kW
9896128
9896129
11000
11000
20/20/20
25/25/25
10000/10000/10000
120~950
Lithium-Ion Battery [LFP]
100~800
108
5000
5500
400/230Vac; 380/220Vac, 3L/N/PE
50/60, ±5
7.6
8.3
1 (Adjustable from 0.8 leading to 0.8 lagging)
<3 @rated power
6000
400/230Vac; 380/220Vac, 3L/N/PE
50/60, ±5
9.1
5000
6000
400/230Vac; 380/220Vac, 3L/N/PE
7.2
1 (Adjustable from 0.8 leading to 0.8 lagging)
<3 @Linear load
AX Plus 8kW
9896130
14000
18000
13200
17600
1000
[1]
620
90
[2]
140
3
1+1+1
100
125
160
50
CAN
6000
8000
6600
8800
9.1
12.1
10
13.3
7200
9600
10.9
14.5
6000
8000
7200
96000
50/60
8.7
11.6
<20
