Installation guide / User manual
AX Plus 5-15kW 3ph Hybrid Inverter
BMS
BMS is used to communicate with the battery for data exchange, please use the
network cable configured for the battery to communicate the communication
distance should not exceed 10m.
- Insert one side of CAT 7 cable into the first inverter's CAN port and the other
side into the next inverter's CAN port.
- Insert one side of CAT 5 cable into the Meter port of meter, and the other side
into the CAN 1 port the first inverter or the CAN 2 port of the last inverter.
NOTE:
PV and battery should both be connected to the inverter with meter
cable plugged.
