Installation guide / User manual
AX Plus 5-15kW 3ph Hybrid Inverter
7.2 RCR wiring
RCR0 setting
SETTINGS
The prerequisite for the use of this function is the selection of the German grid
connection regulation VDE 4105 and the use of the RCR function.
The ripple control function is described below:
PIN
1
Port
DRM
+3.3V
Switching state
No contact closed
Several contacts closed
Contact DRM1 to +3.3V
Contact DRM2 to +3.3V
Contact DRM3 to +3.3V
Contact DRM4 to +3.3V
Contact Drm0 to 3.3V
7.3 SG ready wiring and setting
SG Ready
The Smart Grid Ready is controlled by the dry contact output (PIN1-PIN4) of the
inverter.
0-Relay = open, 1-Relay = closed
atx054en0225
FEATURE
PARM
2
3
DRM1
DRM2
100%
100%
60%
30%
0%
Immediate OFF
AC Max.Chr power limit to 4.2kw under Vde4105 Safty
Lable
Mode 1
DRY_RLY2-
Mode 2
Mode 3
Mode 4
Modus 4
RCR
4
5
DRM3
DRM4
Output active power (%Pn)
Relay-2
1
2
DRY_RLY2+
1
0
0
1
ENABLE/DISABLE
6
7
DRM0
GND
Relay-1
3
DRY_RLY1-
DRY_RLY1+
0
0
1
1
8
GND
4
