Installation guide / User manual
AX Plus 5-15kW 3ph Hybrid Inverter
Insert L1/L2/L3/N wires and RS485A/B cable into the meter.
Please refer to the meter wiring diagram on side of meter itself.
PIN
1
Port
Meter
Meter
485B
Page 116
Meter
24: 485A
25: 485B
2 3
Meter
/
485A
4 5
/ /
Grid
Load
6 7
Meter Meter
/
485B
atx054en0225
8
485A
