1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Str. 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoyment
and success.
Exclusion of liability
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability
for damage to the product or caused by the product
arising from:
• Improper handling,
• Non-compliance with the operating manual,
• Repairs carried out by third parties, unauthorised
specialists,
• Installing and replacing non-original spare parts,
• Application other than specified.
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / 0113 not being observed.
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper
and economic operation of the product, for avoiding
danger, for minimising repair costs and downtimes and
for increasing the reliability and extending the service
life of the product. In addition to the safety instructions
in this operating manual, you must also observe the
regulations applicable to the operation of the product
in your country.
Familiarise yourself with all operating and safety in-
structions before using the product. Only operate the
product as described and for the specified areas of ap-
plication. Keep the operating manual in a good place
and hand over all documents when passing the product
on to third parties.
2. Description of the product
1. Saw table
2. Saw blade guard
2a. Locking pin
3. Riving knife
3a. Fixing screw
4. Saw blade
4a. Inner flange
4b. Outer flange
4c. Flange screw
5. Table inlay
5a. Phillips screw
6. Stop rail
7. Parallel stop
7a. Star grip nut
7b. Washer
7c. Hexagonal bolt
8. Push stick
8a. Push rod retainer
9. Clamping lever
10. Hand wheel
11. Angle adjustment clamp
12. On/off switch
13. Reset button
14. Cable holder
15. Groove cross-cutting gauge
16. Transverse cutting gauge
17. Locking handle cross-cutting gauge
18. Suction adapter
19. Scale
3. Scope of delivery (Fig. 1a)
Item
2
7
7 a
7b
7c
8
16
A
B
4. Proper use
The circular table saw is used for the longitudinal and
transverse cutting (only with the mitre gauge) of all
types of timbers and plastic, in accordance with the
machine size. It is not permitted to cut any type of
round timber.
www.scheppach.com
Quantity Designation
1x Saw blade guard
1x Parallel stop
2x Star grip nut
2x Washer
2x Hexagonal bolt
1x Push stick
1x Transverse cutting gauge
1x 22 mm open-ended spanner
1x Allen key, 6 mm
Operating manual
