Standards and directives complied with
Standard / directive Description
EN 61000-6-2 Electromagnetic compatibility (EMC); part 6-2: Generic standards –
interference immunity for industrial environments
EN 61010-1 Safety requirements for electrical equipment for measurement, con-
trol, and laboratory use - Part 1: General requirements
Pneumatics
Specifications
Permissible medium Compressed air as per ISO 8573-1:2010 (7-4-4)
Solid particles class 7 Mass concentration: 5-10 mg/m³
Water class 4 Pressure dew point, vapor: ≤ +3 °C
Oil class 4 Oil content: ≤ 5 mg/m³
Medium temperature 5 °C ... 50 °C
Ambient temperature 5 °C ... 50 °C
Storage temperature -25 °C ... 80 °C
Flow rate at pilot pressure: ED07: 2200 l/min
11 bar
ED12: 4700 l/min
Nominal pressure: 10 bar
Pressure drop: 1 bar
Table 8: Pressure specifications
Supply pressure
Output pressure
Reproducibility at 10 bar output pressure 0.01 bar
Hysteresis at 10 bar output pressure
15 Spare parts
Information on spare parts can be found on the product page in the Emerson
store.
16 Accessories
Information on accessories can be found on the product page in the Emerson
store.
Description
Angled socket M12, 5-pin, A-coded for XPC
Flat subbase ED07 with D12 plug-in cartridge and silencer
Mounting set, ED07 series (sheet metal for mounting of ED07 flat sub-
base (5610231002))
Single subbase ED07
Base plate, ED07 series (for stacking assembly)
End plate left, end plate right for ED07 base plate
Gasket, ED07 series (1x gasket and 4x screws DIN 912 - M5x90)
Silencer, SI1 series for single subbase, ED07 series (5610211052), and
base plate for stacking assembly, ED07 series (8985049932)
Single subbase, ED12 series
Base plate, ED12 series (for stacking assembly)
End plate left, end plate right for base plate; ED12 series
Base plate gasket, ED12 series
(1x base plate gasket and 4x screws DIN 912 - M6x70)
Silencer, SI1 series
Single subbase, ED12 series
Base plate for stacking assembly, ED12 series
17 Declaration of conformity
The declaration of conformity can be found on the product page in the Emerson
store.
AVENTICS™ ED 07 / 12 Profinet | R414014550-BAL-001-AA | English
ED07 ED12
Max. 12 bar
0 ... 10 bar
0.02 bar
0.02 bar 0.03 bar
Item no.
1824484029
5610231002
5530010522
5610211052
8985049932
1825503145
R414001681
1827000002
5610221012
8985049912
1825503151
05610220092
1827000004
5610221012
8985049912
