iC7-Automation Frequenzumrichter
Projektierungshandbuch
Frequenzumrichter
Produktcode Überlast-
betrieb
05-16A0 Alle
05-24A0 Alle
05-31A0 Alle
05-38A0 Alle
05-43A0 Alle
05-61A0 Alle
05-73A0 Alle
05-90A0 Alle
05-106A Alle
05-147A Alle
05-170A Alle
05-206A LO
HO1
05-245A LO
HO1
05-302A LO
HO1
05-385A LO
HO1
05-395A LO
HO1
05-480A LO
HO1
05-588A LO
HO1
05-685A LO
HO1
05-736A LO
HO1
Danfoss A/S © 2023.05
Passiver Oberschwingungsfilter OF7P2
Eingangsstrom 441– Nennstrom
500 V 440–480 V
60 Hz [A]
RMS [A] Grundwert
[A]
13,4 – –
20,0 – –
26,0 – –
31,0 – –
37,0 – –
50,0 – –
61,0 – –
74,0 – –
90,0 – –
122,0 – –
145,0 – –
189,0 – –
160,0 – –
231,0 – –
189,0 – –
291,0 – –
231,0 – –
350,0 – –
291,0 – –
350,0 – –
291,0 – –
439,0 – –
350,0 – –
501,0 – –
439,0 – –
568,0 – –
501,0 – –
633,0 – –
568,0 – –
Bestellen des Frequenzumrichters
IP20/UL Open Type
AHF005
Baugröße Bestell-Nr.
P2AX1e 132N6492
P2AX2e 132N6496
P2AX2e 132N6497
P2AX3i 132N6498
P2AX3i 132N6499
P2AX3i 132N6500
P2AX4i 132N6501
P2AX4e 132N6502
P2AX5e 132N6503
P2AX5e 132N6506
P2AX6e 132N6510
P2AX7i 132N6511
P2AX6e 132N6510
P2AX7i 132N6512
P2AX7i 132N6511
P2AX8i 132N6513
P2AX7i 132N6512
P2AX8e 132N6514
P2AX8i 132N6513
P2AX8e 132N6514
P2AX8i 132N6513
P2AX8e 132N9615
P2AX8e 132N6514
P2AX8i 2 x 132N6513
P2AX8e 132N9615
P2AX8i 2 x 132N6513
P2AX8i 2 x 132N6513
P2AX8e 2 x 132N6514
P2AX8i 2 x 132N6513
AJ319739940640de-000301 / 136R0269 | 135
AHF010
Baugröße Bestell-Nr.
P2AX1e 132N6786
P2AX2i 132N6787
P2AX2i 132N6788
P2AX3i 132N6789
P2AX3i 132N6790
P2AX3i 132N6791
P2AX4i 132N6792
P2AX4e 132N6793
P2AX5e 132N6794
P2AX5e 132N6795
P2AX6i 132N6796
P2AX6i 132N6798
P2AX6i 132N6796
P2AX7i 132N6799
P2AX6i 132N6798
P2AX7i 132N6800
P2AX7i 132N6799
P2AX7e 132N6801
P2AX7i 132N6800
P2AX7e 132N6801
P2AX7i 132N6800
P2AX8e 132N9617
P2AX7e 132N6801
P2AX7i 2 x 132N6800
P2AX8e 132N9617
P2AX7i 2 x 132N6800
P2AX7i 2 x 132N6800
P2AX7e 2 x 132N6801
P2AX7i 2 x 132N6800
