CAUTION
▪ Keep the practice model in a cool place away from direct sunlight. A discolored practice model may affect the results of the practice mode.
▪ The strap is designed specifically for the weight of the i700 wireless and should not be used with other products.
▪ Medit Scan for Clinics is included in the USB drive. This product is optimized for PC, and using other devices is not recommended.
Do not use anything other than a USB port. It may cause malfunction or fire.
▪ The auto-calibration tool is not included in the i700 wireless package. It can be bought separately from your place of purchase.
1.7

Setting Up the i700 wireless System

1.7.1

Basic Settings of i700 wireless

Connect the i700 wireless Wireless Hub (1)
① Connect the USB 3.0 cable (C to A) to the wireless hub.
③ Connecting the power cord to the adapter
automatically powers the wireless hub.
Connect the i700 wireless Wireless Hub (2)
① Connect the power delivery cable (C to C) to the
wireless hub.
Turning On the i700 wireless
① Insert the battery into the i700 wireless
handpiece and press the power button.
6 User Manual
② Connect the adapter to the wireless hub.
④ Connect the USB 3.0 cable's A port connector to a PC.
※ The USB port is used only for signal transmission.
② Connect the power delivery cable to a PC.
※ 9 Vdc power is supplied to the USB port.
② When the power is supplied, the LED on the upper
part of the i700 wireless handpiece turns blue.
