The riving knife should never be thinner than the body
of the saw blade or thicker than the cutting joint width.
Only use saw blades with a diameter of 315 mm and a
thickness of 2.4 mm (3.0 mm / 3,2 mm teeth).
Lower the suction hood onto the workpiece during
every working cycle. The hood must be positioned
horizontally above the saw blade during every work-
ing cycle.
Length Cuts
Insert the length stop for parallel cuts.
Use the stop ruler with the high stop side for cuts
above 120 mm and the stop ruler with the low stop
side for cut widths under 120 mm.
Lead the workpiece with the push stick.
Diagonal Cuts
For diagonal and angle cuts, insert the cross-cutting
guide.
Working on circular saws
Cutting wide workpieces, Fig. 24
Width of the workpiece to be machined over 120 mm
Operating cycle: Adjust the ripping fence in accord-
ance with the width of the workpiece. Ensure that
your hands are resting in a safe place. The work-
piece may only be forward-fed in the tool area with
the right hand or with the aid of a push-stick if narrow
workpieces are cut off in the cutting process. Move
the fence back to the middle of the saw or use a
short auxiliary fence if there is a danger of the work-
piece being jammed between the circular sawblade,
the riving knife and the fence.
Only the upper suction hood has been left out in the
individual case in order to display the operating cycle
or device more clearly.
The upper suction hood is required for all of the op-
erating cycles.
Cutting narrow workpieces, Fig. 25
Be sure to use a push stick when making longitudinal
cuts in workpieces smaller than 120 mm in width. A
push block is supplied with the saw! Replace a worn
or damaged push stick immediately.
• Adjust the parallel stop to the width of workpiece
you require.
• Feed in the workpiece with two hands. Always use
the push stick in the area of the saw blade.
• Always push the workpiece through to the end of
the splitter.
Caution! With short workpieces, use the push stick
from the beginning.
30 | GB
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
Cutting edges and strips, Fig. 26
Operating cycle: Mount the fence with a low stop bar
surface or use an auxiliary fence. Feed the work-
piece with a push-stick until the end of the workpiece
is in the region of the riving knife. Prevent long work-
pieces from toppling over at the end of the cutting
process by using a table length extension.
Making cross cuts, Fig. 27
Operating cycle: Adjust the rejection rail so that
workpiece sections do not touch the ascending part
of the sawblade. Only feed the workpiece by means
of a crossfeed stop or a cross slide.
Do not remove wood chippings from the region of the
workpiece with your hands.

10. Maintenance

Warning! Prior to any adjustment, maintenance or
service work disconnect the mains power plug!
General maintenance measures
• Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
down with compressed air at low pressure.
• We recommend that you clean the equipment im-
mediately after you use it.
• Clean the equipment regularly with a damp cloth
and some soft soap. Do not use cleaning agents
or solvents; these may be aggressive to the plastic
parts in the equipment. Ensure that no water can
get into the interior of the equipment.
• In order to extend the service life of the tool, oil
the rotary parts once monthly. Do not oil the motor.
Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: Carbon brush, saw blade, batteries, ta-
ble liners, sliding stand, push handle, V-belts
* Not necessarily included in the scope of delivery!

11. Storage

Store the device and its accessories in a dark, dry
and frost-proof place that is inaccessible to children.
The optimum storage temperature is between 5 and
30˚C.
Cover the electrical tool in order to protect it from
dust and moisture.
Store the operating manual with the electrical tool.
