Cutting very narrow Workpieces
For longitudinal cuts of very narrow workpieces with a width of
30 mm and less, a push block must be used without fail. There
is no push block included in the scope of delivery! (Available
from specialist shops) Replace a worn push block as soon as
possible.
• The parallel stop should be adjusted to the cutting width of
the workpiece.
• Press the workpiece with the push block against the stop rail
and push the workpiece with the push stick (17) through to
the end of the riving knife.
Performing Bevel Cuts (Fig. AG)
• All bevel cuts are made using the parallel stop (14).
• Adjust the saw blade to the desired angle.
• Adjust the parallel stop (14) according to the workpiece
width and height.
• Perform the cut according to the workpiece width
Performing Transverse Cuts (Fig. AH)
• Push the transverse stop (31) into one of the two grooves
(28a/b) of the saw table. Adjust to the desired angle. The
left groove (28a) is to be used if the saw blade (4) also has
to be positioned at an oblique angle. This will prevent your
hand and the transverse stop from coming into contact with
the saw blade guard.
• Use the stop rail.
• Press the workpiece irmly against the transverse stop (31).
• Switch on the saw.
• Push the transverse stop (31) and workpiece in the direction
of the saw blade in order to perform the cut.
Caution:
Always hold the guided workpiece irmly and nev-
er the free workpiece which is cut off.
• Always push the transverse stop (31) so far forwards until
the workpiece is completely cut through.
• Switch the saw off again. Only remove sawing waste when
the saw blade has come to a standstill.
Cutting chipboard
• To prevent the cutting edges from breaking when cutting
chipboard, do not set the saw blade higher than 5 mm
above the thickness of the workpiece.
After sawing
1. Switch off the circular table saw first and then the extrac-
tion unit. The saw blade continues to run for a longer
time.
2. Do not remove the cut waste on the saw table until the
saw blade has returned to its rest position.
3. Disconnect the circular table saw from the mains by pull-
ing the mains plug out of the power outlet.
4. Allow the circular table saw to cool down completely.
Removing trapped material
m WARNING! Risk of injury!
Improper handling of the circular table saw may result in seri-
ous injury.
38 GB/IE/NI
• Switch off the circular table saw immediately and discon-
nect the mains plug from the power outlet if the saw blade is
jammed in the workpiece or other blockages occur.
• Use protective gloves and do not touch the saw blade with
your bare hands.

13. Transport

1. Turn the power tool off before it is transported and dis-
connect it from the power supply.
2. Always carry the electric tool with at least one other per-
son. Do not carry the machine by the table extensions,
but only lift it by the housing.
3. Protect the power tool against knocks, jolts and strong
vibrations, e.g. when it is transported in motor vehicles.
4. Secure the power tool against tilting and sliding.
5. Never use the protective devices for handling or trans-
port.

14. Maintenance

m Warning! Prior to any adjustment, maintenance or service
work disconnect the mains power plug!
General maintenance measures
• Keep the safety devices, air vents and motor housing as free
of dust and dirt as possible. Wipe the device off with a clean
cloth or blow it out with compressed air at a low pressure.
• We recommend that you clean the device immediately after
every use.
• Clean the device regularly with a damp cloth and some soft
soap. Do not use any detergents or solvents; these might at-
tack the plastic parts of the device. Make sure that no water
can get into the interior of the device.
• Oil the moving parts once a month in order to extend the tool
life. Do not oil the motor.
Carbon brushes
If excessive sparks are generated, have an electrician check
the carbon brushes. Attention! The carbon brushes must only
be replaced by an electrician.
Service information
Please note that the following parts of this product are sub-
ject to normal or natural wear and that the following parts are
therefore also required for use as consumables.
Wear parts*: Carbon brush, saw blade, batteries, table inserts,
push stick, push handle, V-belt
* Not necessarily included in the scope of delivery!

15. Storage

Store the device and its accessories in a dark, dry and frost-
proof place that is inaccessible to children. The optimum stor-
age temperature is between 5 and 30˚C.
Store the electrical tool in its original packaging.
Cover the electrical tool in order to protect it from dust and
moisture.
Store the operating manual with the electrical tool.
