I/O Panel
17
18
No. Description
1 PS/2 Mouse/Keyboard Port
2 Central / Bass (Orange)
3 Rear Speaker (Black)
4 Line In (Light Blue)
5 Front Speaker (Lime)*
6 LAN RJ-45 Port
(Dragon RTL8125BG)**
7 LAN RJ-45 Port (Intel® I219V)***
8 USB 3.2 Gen1 Ports (USB3_4_5)**** 17
9 USB 3.2 Gen1 Type-A Port
(USB3_3)
2
1 3
15
14 13
16
No. Description
10
11
12
13
14
15
16
18
4
6
5 7
11
12
10
USB 3.2 Gen2x2 Type-C Port
(USB32_TC_1)
USB 3.2 Gen2 Ports (USB31_1_2)
Microphone (Pink)
Optical SPDIF Out Port
USB 3.2 Gen1 Ports (USB3_12)
DisplayPort 1.4
HDMI Port
Antenna Ports (on I/O Panel Shield)
BIOS Flashback Button
Z490 Taichi
9 8
3
