Turbo-V 301 Rack Controller Description

The controller is available in three models (see orderable parts table):
The controller is a solid-state frequency converter with the following
features:
See the following diagram for the connections and orderable parts.
Turbo-V 301-AG Rack Controller User Manual / 87-900-982-01
base version
with RS 232-485 option
with Profibus option
Drives the pumps of the 301-NAV family.
Powers the pump cooling fan
Drives the vent valve.
Provides and acquires the pressure of the wide range gauge.
Remote I/Os compatible with the previous version.
Navigator default serial compatible with the previous RS 232 and
485 version.
Speed reading after stop command.
Technical Information
