Pins Name
2-1 Programmable
Analog Output
9-1 Frequency
Analog Output
Turbo-V 301-AG Rack Controller User Manual / 87-900-982-01
Description
Programmable analog output.
Can be related to : frequency,
power, pump temperature
(linear) or pressure
(logarithmic). The setting can
be done by: front panel or
serial line (win.111).
0V = 0Hz, 0W, 0°C
10V = 963Hz, 150W, 100°C
See following chart for more
details
Analog output proportional to
frequency (linear).
0V = 0Hz
10V = 963Hz
Technical Information
Controller Connection
Electrical Note
Optically isolated Connect a 100kohm
Rload, min = 10kr resistor between the 2
Ripple Vpp,max = pins before measuring
200mv voltage
Precision = 5%
Resolution = 40mv
Pin-1negative
Pin-2 positive
Optically isolated
Rload, min = 10kr
Ripple Vpp,max =
200mv
Precision = 1%
Resolution = 40mv
Pin-1negative
Pin-9 positive
