17 Technical Information
Examples
110 R/W L
111 R/W L
117 R/W N
120 R/W N
122 R/W L
123 Reserved to Agilent service
124
125 R/W L
126 R/W N
130 Reserved to Agilent service
143 R/W N
144 R/W L
147 R/W N
155 R N
157 R/W N
161 R/W N
162 R/W A
242/294
Interlock type (default = 0)
Analog output type: output voltage signal
proportional to frequency or power
Low Speed frequency (Hz)
Rotational frequency setting (Hz)
Set vent valve on/off (on = closed)
Set the vent valve operation
Vent valve opening delay (expressed in 0.2
sec)
External Fan Configuration
External Fan Activation
Vent open time
See "vent connector" paragraph
Power limit applied
Read the maximun allowable power
Gas load type.
Select the gas load to the pump
Pressure Reading Connection Factor
See "GAUGE CONNECTOR" for more details
R1 Set Point Pressure Valve
Valid if min. 101 = 4
Format X.X E. XX
Where X = 0 to 9 s = + or -
Turbo-V 301-AG Rack Controller User Manual / 87-900-982-01
Impulse = 0
Continuous = 1
0 = frequency
1 = power
(default = 1)
2 = Pump temperature
3 = Pressure
700 to 963
(default = 700)
Low speed
frequency (win 117)
to 963
(default = 963)
On = 1
Off = 0 (default = 1)
Automatic = 0 (see note 1.)
On command = 1 (see note
2.)
0 to 65535 (corresponding to
0 to 13107 sec)
0 = ON
1 = automatic
2 = serial
(default = 2)
0 = OFF
1 = ON
(default = 0)
0 = infinite
1 bit = 0.2 sec
watt
Ø = N
2
1 = Av
0 to 10
0 = 0
10 = 1 = N
2
(F)
