17 Technical Information
Profibus Option
20 1
21 1
276/294
B = Vent & Purge Auto/Man
0
0 = Auto (the controller drives purge and vent
valves automatically)
1 = Manual (the user can command the valves by
serial line or profibus)
B = Gas Load Type. Select here the gas load
1
0 = Ar
1 = N2
B = Interlock Type
2
0 = continuos (the interlock must be always present
to run the pump)
1 = at start (the interlock must be present only at
start command)
B = Setpoint R1 Logic
3
0 = active close (NO)
1 = active open (NC)
B = Setpoint R2 Logic
4
0 = active close (NO)
1 = active open (NC)
B - = Pressure Unit
5 6
0 = mbar
1 = Pascal
2 = Torr
B = Reserved
7
B - = Setpoint R1 Type
0 2
0 = frequency
1 = current
2 = time
3= normal operation
4= pressure
B = Setpoint R2 Type
3-5
0 = frequency
1 = current
2 = time
3= normal operation
4= pressure
B - = Analog Output 1 Type
6 7
0 = frequency
1 = power
2 = temperature
3= pressure
Turbo-V 301-AG Rack Controller User Manual / 87-900-982-01
