Programmable Analog Output Diagrams

Programmable Analog Output Diagrams

Figure 19
Figure 20
Figure 21
222/294
V (Volt)
Output Voltage
10
0
Diagram 1 – Programmable analog output related to frquency
V (Volt)
Output Voltage
10
0
Diagram 2 – Programmable analog output related to power
V (Volt)
Output Voltage
10
0
Diagram 3 – Programmable analog output related to pump
temperature
Turbo-V 301-AG Rack Controller User Manual / 87-900-982-01
963
Frequency (Hz)
150
Power (W)
100
Pump Temp (°C)
(F)
