17 Technical Information
Profibus Option
Tab. 16
Status
POWER_ON
WAIT_PRM
WAIT_CFG
DATA_EX
Figure 46
Tab. 17
Status
POWER_ON
SRC_ADDR
IDENTIFY
DATA_EX
272/294
Profibus state machine
Internal link state machine
Turbo-V 301-AG Rack Controller User Manual / 87-900-982-01
Meaning
Interface set-up
Wait for parameterisation from the master
Wait for configuration from the master
Regular data exchange
Meaning
Interface set-up
Search for the controller serial address
Identify controller model and protocol
Regular data exchange
