FRONT: front mode (the controller accepts START/STOP and LOW
SPEED commands from the front panel)
REMOTE: remote mode (the controller accepts START/STOP and
LOW SPEED commands via the rear connector)
RS232: the controller accepts commands from the serial port
according to the RS232 standard.
RS485 [XX]: the controller accepts commands from the serial port in
RS485 mode with address XX (XX from 0 to 31)
PROFIBUS [YYY]: the controller accepts commands from the
PROFIBUS port with address YYYY
Black rectangles as shown below may be displayed at any time in the
first and last box of the bottom line of the display (opposite the LS /
AG / R1 / R2 captions). The meaning of these rectangles is as follows:
LS → the controller is at LOW SPEED
AG → the Gauge is connected to the controller
R1 → relay (set point) R1 is active
R2 → relay (set point) R2 is active
Figure 30
Turbo-V 301-AG Rack Controller User Manual / 87-900-982-01
LS
AG
Technical Information
How to Use by Front Panel
(F)
17
R1
R2
