Where:
P = XXX W is the current power supplied to the pump
T = XX °C is the current temperature of the pump
XXXX Hz is the current frequency of rotation of the pump. This value
is set by default to 963 Hz but can be modified by the user according
to needs, proceeding as described in the "PROGRAMMING"
paragraph. The unit of measurement (HZ / Krpm, default = Hz) is
selected by the user from the INPUT/OUTPUT->SPED menu.
If the SOFT-START function (PUMP SETTING menu → SOFTSTART
is active and the pump is ramping, indication of the speed of rotation
is replaced with a bar-graph that indicates the soft-start step in
course and the total number of steps to be performed. On completion
of the soft-start ramp, the bar-graph is replaced with indication of the
frequency of rotation of the pump
Pressing twice, the following is obtained:
N
Where:
NORMAL: indicates the operating regime of the pump
XXXHz: see description "Pressing once" Measures key
I=X.XXA: indicates the current absorbed by the pump
V= XXX V: indicates the pump driving voltage
Pressing 3 times, the following is obtained:
P
Where:
P= XXXW: indicates the current power supplied to the pump
XXXHz: see description "Pressing once" Measures key
