K-MAR-5200 Instructions for Use

Explanation of Pictograms

1

How to use this Manual

The following pictograms appear on the Vacuum Pump and the Disposable Vacuum
Line with Hydrophobic Filter (K-DVLF-240)
Before connection, read the manual!
Refer to IFU – Mandatory
Standby/On
Increase Vacuum Set-Point
Decrease Vacuum Set-Point
Boost Vacuum
Patient Tube Connection
Foot Pedal Connection
Symbol for type B equipment
CE – Approval Marking
UL – Approval Marking
Dispose of in accordance with
WEEE directive (2002/96/EC)
Manufacturer
EC REP
US REP

Warnings and Important Notes

Throughout these Instructions for Use, blocks of text may be accompanied by a pictogram and/or printed in
bold type. These instructions point out special service procedures or precautions that must be followed to avoid
damaging the device. These blocks are WARNINGS and IMPORTANT NOTES and they are used as follows:
WARNING: The personal safety of the patient may be involved. Disregarding this information could result
in injury to the operator, device or the contents!
WARNING: Biological hazard
WARNING: Electric shock hazard
WARNING: Explosion hazard
IMPORTANT NOTE: This provides special information that facilitates maintenance or clarifies important
instructions. Please pay particular attention to the Safety Instructions (see §1).

Manual Structure

This manual has a table of contents (page 2) to help you find section titles quickly. There is a troubleshooting guide
on page 17 to help you to trouble shoot problems.
1-3
EC Representative
EC REP
US REP Catalogue Code
REF
REF
SN
Serial Number
SN
Degree of enclosure protection from
IP41
solid objects and liquids
Do not reuse
(1)
Do not use if packaging is damaged
Keep away from sunlight
Keep dry
Batch code
Date of Manufacture
(1) Use-by Date
Note (1): Symbols are on sterile Disposable Vacuum Line
with Hydrophobic Filter (K-DVLF-240) packaging
only.
English
