K-MAR-5200 Instructions for Use

8. Technical Data

Classification according to IEC 60601-1
Type of protection against electric shock:
Degree of protection against electric shock:
Degree of protection against harmful ingress of solids and water:
Specifications
Power Supply:
Frequency:
Maximum current:
Maximum power consumption:
Environmental operating conditions:
Storage and transport directions:
Manufactured and tested to the following standards:
Performance class:
Dimensions:
Weight:
Vacuum Ranges:
Vacuum Range Accuracy:
Guidance and manufacturer's declaration – electromagnetic emissions
The Vacuum Pump is intended for use in the electromagnetic environment specified below. The customer or the end user of the Vacuum Pump should assure
that it is used in such an environment.
Emissions Test Compliance
RF emissions Group 1
CISPR 11
RF emissions Class B
CISPR 11
Harmonic emissions Class A
IEC 61000-3-2
Voltage fluctuations/ Complies
flicker emissions
IEC 61000-3-3
Class I equipment
Type B
IP41
100 - 240 VAC
50 - 60 Hz
500 mA (115 VAC)
250 mA (240 VAC)
60 VA
+5°C to +35°C
10% to 75% RH
700 hPa to 1060 hPa
+5°C to +40°C
10% to 75% RH
IEC 60601-1: 1988 + A1: 1991 + A2: 1995
IEC 60601-1: 2005 + A1: 2012(E)
IEC 60601-1-2: 2014
ISO 10079-1: 2015
ANSI/AAMI ES60601-1(2005 + C1: 09 + A2: 10),
CAN/CSA-C22.2 No. 60601-1(2008), E363262
High Vacuum / Low Flow (ISO 10079-1)
200 mm wide x 100 mm high x 350 mm deep
3.2 kg (7.1 lb)
-10 mmHg to -500 mmHg in 1 mmHg increments.
-1.0 kPa to -67.0 kPa in 0.1 kPa increments.
±5 mmHg (±0.7 kPa)
Electromagnetic Environment Guidance
The Vacuum Pump uses RF energy only for its internal function. Therefore, its RF emissions are very low and
are not likely to cause any interference in nearby electronic equipment.
The Vacuum Pump is suitable for use in all establishments, including domestic establishments and those
directly connected to the public low voltage power supply network that supplies buildings used for
domestic purposes.
1-14
VACUUM PUMP WITH RESPECT TO ELECTRICAL SHOCK, FIRE AND
MECHANICAL HAZARDS ONLY IN ACCORDANCE WITH:
