K-MAR-5200 Instructions for Use
Recommended separation distance between portable and mobile RF communications equipment and the Vacuum Pump
The Vacuum Pump is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of
the Vacuum Pump can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications
equipment (transmitters) and the Vacuum Pump as recommended below, according to the maximum output power of the communications equipment.
Rated maximum output power
of transmitter
(W)
0.01
0.1
1
10
100
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in metres (m) can be estimated using the
equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the
transmitter manufacturer.
Note 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects,
and people
Proximity fields from RF wireless communication equipment
Test frequency Band
a
(MHz) (MHz)
385 360-390
450 430-470
710
745 704-787
780
810
870 800-960
930
1720
1845 1700-1990
1970
2450 2400-2570
5240
5500 5100-5800
5785
Note: if necessary to achieve the IMMUNITY test level, the distance between the transiting antenna and the ME equipment or ME system may be reduced to
1m. The 1m test distance is permitted by IEC 61000-4-3.
a For some services, only the uplink frequencies are included.
b The carrier shall be modulated using a 50% duty cycle square wave signal.
c As an alternative to FM modulation, 50% pulse modulation at 18Hz may be used because while it does not represent actual modulation, it would be worst case.
Separation distance according to frequency of transmitter
150 kHz to 80 MHz
(d = 1.2 √P)
0.12
0.38
1.2
3.8
12
Service Modulation
a b
Pulse
TETRA 400 modulation b
18 Hz
FM C
GMRS 460
±5 kHz deviation
FRS 460
1 kHz sine
Pulse
LTE Band 13,17 modulation b
217 Hz
GSM 800/900
TETRA 800 Pulse
iDEN 820 modulation b
CDMA 850 217 Hz
LTE Band 5
GSM 1800
CDMA 1900 Pulse
DECT modulation
b
LTE Band 1, 3, 217 Hz
4, 25; UMTS
Bluetooth
WLAN Pulse
802.11 b/g/n RFID modulation b
2450 217 Hz
LTE Band 7
Pulse
WLAN 802.11
modulation b
a/n
217 Hz
1-16
(m)
80 MHz to 800 MHz
(d = 1.2 √P)
0.12
0.38
1.2
3.8
12
Maximum Distance Immunity test
power (m)
(W)
1.8 0.3
2 0.3
0.2 0.3
2 0.3
2 0.3
2 0.3
0.2 0.3
English
800 MHz to 2.5 GHz
(d = 2.3 √P)
0.23
0.73
2.3
7.3
23
Minimum
level separation distance
(V/m) (m)
27 0.3
28 0.3
9 0.3
28 0.3
28 0.3
28 0.3
9 0.3
