Changing to "LiveDisplay"

1
Truma Diagnose Tool / Error Explorer
File Tools ?
Open ...
Open ...
2
Save as ...
Save as ...
Print
Print
Live Display
Live Display p y
Exit
Exit
Fig. 38

Closing the program

1
Truma Diagnose Tool / Error Explorer
File Tools ?
Open ... Open ...
Save as ...
Save as ...
2
Print
Print
Live Display
Live Display
Exit
Exit
Fig. 39
– Disconnect the diagnostics cable from the test object.
– Switch off the device.
24
1 Click on "File".
2 Select "Live Display".
– "ErrorExplorer" will
close.
– "Live Display" will start
up.
1 Click on "File".
2 Click on "Exit".
"Live Display" program – Combi
Display or change of operating states and parameters
Requirements for operation:
Device Version of software in the device
Combi (Gas) All
Combi D > V 04.00.00
Mover® –

Program start-up

1
2
Fig. 40

Device search

1
Truma Diagnose Tool / Livwe Display
2
File Tools ?
Start
Stop
Properties
Select language
3
Fig. 41
The operating parameters will be displayed in a box if the
search is successful.
The example shows the Combi (Gas) device.
1
Fig. 42
Screen displaying current action
1 Device search
2 Hardware and software initialisation
3 Communication between PC and device
– Green flashing light – error-free communication
– Red light – interruption
1 Start the program by
double-clicking on the
"Truma Diagnose Tool"
icon on the desktop.
2 Select "Live Display" to
start the program.
1 Click on "Tools".
2 Click on "Start".
3 Search results or
information on the
device detected
2 3
